Pelet
Offering maximum heating performance in tight spaces with its compact design, Lidya Compact Series is user-friendly with automatic fuel supply and modulating control panel.
Color Option
White
Lidya Compact Plus; Automatic fuel loading,
Automatic ignition, Automatic cooker cleaning,
Features such as automatic smoke pipe cleaning
as well as a smart card with wireless control
provides comfortable ease of use.
And thanks to the side-loading fuel tank
And up to 300 liters of storage capacity.
General Features
Technical Specifications
Documents
Images & Videos
It offers “Automatic Fuel Loading” by rotating the auger with the help of the electronic fuel feeding motor. In this way, both
without leaving your seat and with balanced fuel consumption
you can warm up.
Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then you will need to hold it in your hand to make it work.
In as little as 5 “minutes”, it will automatically perform the ignition.
Tabiki de bu kadar işi kendisi yapan bir cihaz kendisini temizlemezse olmazdı. That's why we have developed the “Automatic Cooker Cleaning” system. This system is activated after the appliance stops working and opens and closes the stainless steel cooker sharply, allowing all the ashes to be discharged into the ash drawer underneath.
(Don't forget to empty the ash drawer).
What about the electronic board that controls all this hardware?
Here is some information about the electronic board we designed:
With this card, you can control the device wirelessly, manage it fully automatically and set up a weekly program to create an automatic work schedule.
It offers “Automatic Fuel Loading” by rotating the auger with the help of the electronic fuel feeding motor. In this way, both
without leaving your seat and with balanced fuel consumption
you can warm up.
Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then you will need to hold it in your hand to make it work.
In as little as 5 “minutes”, it will automatically perform the ignition.
Tabiki de bu kadar işi kendisi yapan bir cihaz kendisini temizlemezse olmazdı. That's why we have developed the “Automatic Cooker Cleaning” system. This system is activated after the appliance stops working and opens and closes the stainless steel cooker sharply, allowing all the ashes to be discharged into the ash drawer underneath.
(Don't forget to empty the ash drawer).
What about the electronic board that controls all this hardware?
Here is some information about the electronic board we designed:
With this card, you can control the device wirelessly, manage it fully automatically and set up a weekly program to create an automatic work schedule.
It offers “Automatic Fuel Loading” by rotating the auger with the help of the electronic fuel feeding motor. In this way, both
without leaving your seat and with balanced fuel consumption
you can warm up.
Of course, you do not need to ignite the loaded fuel with your hand. The device will automatically load the fuel level in line with the temperature value you set, and then you will need to hold it in your hand to make it work.
In as little as 5 “minutes”, it will automatically perform the ignition.
Tabiki de bu kadar işi kendisi yapan bir cihaz kendisini temizlemezse olmazdı. That's why we have developed the “Automatic Cooker Cleaning” system. This system is activated after the appliance stops working and opens and closes the stainless steel cooker sharply, allowing all the ashes to be discharged into the ash drawer underneath.
(Don't forget to empty the ash drawer).
What about the electronic board that controls all this hardware?
Here is some information about the electronic board we designed:
With this card, you can control the device wirelessly, manage it fully automatically and set up a weekly program to create an automatic work schedule.
MODEL
LIDYA COMPACT 15 PLUS +240 (L)
LIDYA COMPACT 15 PLUS +240 (L)
LIDYA COMPACT 25 PLUS +300 (L)
| Capacity kW | 5-15 |
| Width (A) mm | 910 |
| Length (B) mm | 825 |
| Length (B1) mm | |
| Height (C) mm | 1200 |
| Hot Water Outlet Height (D) mm | 525 |
| Cold Water Inlet Height (E) mm | 243 |
| Flue Outlet Height (F) mm | 155 |
| Flue Diameter mm | 80 |
| Flow – Return inches | 1 |
| Fill – Drain inches | 1/2 |
| Weight kg | 173 |
| Water Capacity lt | 29 |
| Tank Capacity lt | 240 |
| Ash Box Capacity l | |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 40-85 |
| Max. Operating Temperature °C | 90 |
| Reducer Power W | 60 |
| Fan Power W | 50 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 10 |
| Fuel Consumption kg/h | 1.1-3.3 |
| Capacity kW | 5-25 |
| Width (A) mm | 965 |
| Length (B) mm | 965 |
| Length (B1) mm | |
| Height (C) mm | 1320 |
| Hot Water Outlet Height (D) mm | 525 |
| Cold Water Inlet Height (E) mm | 260 |
| Flue Outlet Height (F) mm | 155 |
| Flue Diameter mm | 80 |
| Flow – Return inches | 1 |
| Fill – Drain inches | 1/2 |
| Weight kg | 220 |
| Water Capacity lt | 37 |
| Tank Capacity lt | 300 |
| Ash Box Capacity l | |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 40-85 |
| Max. Operating Temperature °C | 90 |
| Reducer Power W | 60 |
| Fan Power W | 50 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 10 |
| Fuel Consumption kg/h | 1.1-5.6 |
