Aqueous System
KOZ-X Series offers a flexible and efficient heating solution with its ability to burn coal and wood.
Color Option
Red
Our product provides economy
with its highly efficient housing design and
.
General features
Technical Specifications
Documents
Images & Videos
Thanks to the ability of the boiler to burn coal and wood, you can choose your fuel according to your needs. It offers both an economical and environmentally friendly heating solution. The combustion chamber compatible with different fuel types offers ease of use while providing high efficient heating.
Thanks to the ability of the boiler to burn coal and wood, you can choose your fuel according to your needs. It offers both an economical and environmentally friendly heating solution. The combustion chamber compatible with different fuel types offers ease of use while providing high efficient heating.
Thanks to the ability of the boiler to burn coal and wood, you can choose your fuel according to your needs. It offers both an economical and environmentally friendly heating solution. The combustion chamber compatible with different fuel types offers ease of use while providing high efficient heating.
MODEL
KOZ-X 20
KOZ-X 20
KOZ-X 25
KOZ-X 40
KOZ-X 60
KOZ-X 80
KOZ-X 100
| Capacity kW | 24 |
| Width (A) mm | 620 |
| Length (B) mm | 1170 |
| Height (C) mm | 1320 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1320 |
| Flue Outlet Height (F) mm | 1050 |
| Flue Diameter mm | 180 |
| Flow – Return inch | 1 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 300 |
| Water Capacity lt | 80 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 80 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 29 |
| Width (A) mm | 620 |
| Length (B) mm | 1180 |
| Height (C) mm | 1450 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1450 |
| Flue Outlet Height (F) mm | 1220 |
| Flue Diameter mm | 180 |
| Flow – Return inch | 1 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 370 |
| Water Capacity lt | 95 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 80 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 46 |
| Width (A) mm | 620 |
| Length (B) mm | 1180 |
| Height (C) mm | 1540 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1540 |
| Flue Outlet Height (F) mm | 1300 |
| Flue Diameter mm | 180 |
| Flow – Return inch | 1 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 400 |
| Water Capacity lt | 110 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 80 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 69 |
| Width (A) mm | 620 |
| Length (B) mm | 1310 |
| Height (C) mm | 1540 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1540 |
| Flue Outlet Height (F) mm | 1300 |
| Flue Diameter mm | 220 |
| Flow – Return inch | 1 1/2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 450 |
| Water Capacity lt | 130 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 80-105 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 93 |
| Width (A) mm | 710 |
| Length (B) mm | 1420 |
| Height (C) mm | 1630 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1630 |
| Flue Outlet Height (F) mm | 1350 |
| Flue Diameter mm | 220 |
| Flow – Return inch | 2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 520 |
| Water Capacity lt | 175 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 80-105 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 116 |
| Width (A) mm | 710 |
| Length (B) mm | 1420 |
| Height (C) mm | 1720 |
| Cold Water Inlet Height (D) mm | 430 |
| Hot Water Outlet Height (E) mm | 1720 |
| Flue Outlet Height (F) mm | 1470 |
| Flue Diameter mm | 250 |
| Flow – Return inch | 2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 590 |
| Water Capacity lt | 200 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Fan Power W | 240 |
| Ash Drawer Capacity l | 12 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
