Aqueous System
The KYK coal boiler is designed for industrial heating applications, combining high efficiency with an elegant and robust construction. Its long-lasting steel body and strong glass wool and ceramic insulation ensure durability, thermal stability, and reliable long-term operation.
Color Option
White
KYK Coal Boiler combines industrial-strength construction with high-efficiency coal combustion, delivering durability, thermal stability, and fully automated operation for demanding heating applications.
Smart automation, advanced safety systems, intelligent temperature management, and integrated hot water control ensure optimized performance, reduced maintenance, and reliable large-scale heating efficiency.
General Features
Technical Specifications
Documents
Images & Videos
By rotating the auger with the help of the electronic fuel supply motor It offers 'Automatic Refueling'. In this way, you can both leave your seat you can warm up without taking off and with balanced fuel consumption
Of course, you do not need to ignite the loaded fuel with your hand. Device fuel level automatically according to the temperature value you set. and then it will take as little as 5 minutes to get it working. in which the ignition will be carried out automatically.
And let's not forget the smoke pipes that contribute to the heating of the water! is as important as cleaning the stove. But don't panic no need at all! We'll take care of you in an automated way in this area that allows the device to be cleaned. Handles after the device is turned off and then clean it by moving it up and down automatically. controlled by a single motor in combination with the system “Automatic Hearth Cleaning” maximizing energy savings.
Where does the waste from all these cleared areas go? That's where the “Automatic Ash Removal” system gives the answer. The cleaned ash and we transfer the pellet residues to the ash bin located outside the device. This one so that you can periodically empty the ash box in a more sterilized and hygienic way. you can empty it.
The slag layer that forms on the top of the coal can cause flame attenuation and leads to waste of unburned coal. However, Automatic Mixing Our Featured Stove eliminates this problem and provides 100% efficient combustion. provides. Thanks to its innovative design, a powerful and effective warm-up at all times minimizes energy losses. High efficiency, maximum Stay one step ahead for performance now!
With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! Warm all year round, in all seasons this smart system that meets your water needs, offers energy efficiency and superior makes your life easier with its performance. Always enjoy hot water Take it out, don't compromise on your comfort!
Thanks to the Sleep Mode, your boiler is automatically ignited and can be used for long periods of time. certain hours to keep the fire alive during waiting periods periods. This innovative feature ensures uninterrupted comfort and offers maximum energy savings. Your heat is always at the ideal level, energy your productivity at the highest level!
By rotating the auger with the help of the electronic fuel supply motor It offers 'Automatic Refueling'. In this way, you can both leave your seat you can warm up without taking off and with balanced fuel consumption
Of course, you do not need to ignite the loaded fuel with your hand. Device fuel level automatically according to the temperature value you set. and then it will take as little as 5 minutes to get it working. in which the ignition will be carried out automatically.
And let's not forget the smoke pipes that contribute to the heating of the water! is as important as cleaning the stove. But don't panic no need at all! We'll take care of you in an automated way in this area that allows the device to be cleaned. Handles after the device is turned off and then clean it by moving it up and down automatically. controlled by a single motor in combination with the system “Automatic Hearth Cleaning” maximizing energy savings.
Where does the waste from all these cleared areas go? That's where the “Automatic Ash Removal” system gives the answer. The cleaned ash and we transfer the pellet residues to the ash bin located outside the device. This one so that you can periodically empty the ash box in a more sterilized and hygienic way. you can empty it.
The slag layer that forms on the top of the coal can cause flame attenuation and leads to waste of unburned coal. However, Automatic Mixing Our Featured Stove eliminates this problem and provides 100% efficient combustion. provides. Thanks to its innovative design, a powerful and effective warm-up at all times minimizes energy losses. High efficiency, maximum Stay one step ahead for performance now!
With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! Warm all year round, in all seasons this smart system that meets your water needs, offers energy efficiency and superior makes your life easier with its performance. Always enjoy hot water Take it out, don't compromise on your comfort!
Thanks to the Sleep Mode, your boiler is automatically ignited and can be used for long periods of time. certain hours to keep the fire alive during waiting periods periods. This innovative feature ensures uninterrupted comfort and offers maximum energy savings. Your heat is always at the ideal level, energy your productivity at the highest level!
By rotating the auger with the help of the electronic fuel supply motor It offers 'Automatic Refueling'. In this way, you can both leave your seat you can warm up without taking off and with balanced fuel consumption
Of course, you do not need to ignite the loaded fuel with your hand. Device fuel level automatically according to the temperature value you set. and then it will take as little as 5 minutes to get it working. in which the ignition will be carried out automatically.
And let's not forget the smoke pipes that contribute to the heating of the water! is as important as cleaning the stove. But don't panic no need at all! We'll take care of you in an automated way in this area that allows the device to be cleaned. Handles after the device is turned off and then clean it by moving it up and down automatically. controlled by a single motor in combination with the system “Automatic Hearth Cleaning” maximizing energy savings.
Where does the waste from all these cleared areas go? That's where the “Automatic Ash Removal” system gives the answer. The cleaned ash and we transfer the pellet residues to the ash bin located outside the device. This one so that you can periodically empty the ash box in a more sterilized and hygienic way. you can empty it.
The slag layer that forms on the top of the coal can cause flame attenuation and leads to waste of unburned coal. However, Automatic Mixing Our Featured Stove eliminates this problem and provides 100% efficient combustion. provides. Thanks to its innovative design, a powerful and effective warm-up at all times minimizes energy losses. High efficiency, maximum Stay one step ahead for performance now!
With the boiler sensor and boiler pump start-up feature, your boiler is now guaranteed to produce hot water in summer and winter! Warm all year round, in all seasons this smart system that meets your water needs, offers energy efficiency and superior makes your life easier with its performance. Always enjoy hot water Take it out, don't compromise on your comfort!
Thanks to the Sleep Mode, your boiler is automatically ignited and can be used for long periods of time. certain hours to keep the fire alive during waiting periods periods. This innovative feature ensures uninterrupted comfort and offers maximum energy savings. Your heat is always at the ideal level, energy your productivity at the highest level!
MODEL
KYK 30
KYK 30
KYK 45
KYK 70
| Capacity kW | 36 |
| Width (A) mm | 800 |
| Length (B) mm | 1720 |
| Height (C) mm | 1700 |
| Cold Water Inlet Height (D) mm | 530 |
| Hot Water Outlet Height (E) mm | 1335 |
| Chimney Outlet Height (F) mm | 1720 |
| Chimney Diameter mm | 168 |
| Flow – Return inch | 1 1/2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 500 |
| Water Capacity lt | 110 |
| Chamber Capacity lt | 225 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Reducer Power W | 180 |
| Fan Power W | 105 |
| Ash Box Capacity l | 50 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 54 |
| Width (A) mm | 800 |
| Length (B) mm | 1720 |
| Height (C) mm | 1800 |
| Cold Water Inlet Height (D) mm | 530 |
| Hot Water Outlet Height (E) mm | 1435 |
| Chimney Outlet Height (F) mm | 1820 |
| Chimney Diameter mm | 168 |
| Flow – Return inch | 1 1/2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1/2 |
| Weight kg | 535 |
| Water Capacity lt | 130 |
| Chamber Capacity lt | 225 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Reducer Power W | 180 |
| Fan Power W | 105 |
| Ash Box Capacity l | 50 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
| Capacity kW | 81 |
| Width (A) mm | 900 |
| Length (B) mm | 1950 |
| Height (C) mm | 1800 |
| Cold Water Inlet Height (D) mm | 210 |
| Hot Water Outlet Height (E) mm | 1410 |
| Chimney Outlet Height (F) mm | 1800 |
| Chimney Diameter mm | 219 |
| Flow – Return inch | 1 1/2 |
| Expansion Outlet inch | 1 |
| Fill – Drain inch | 1 |
| Weight kg | 700 |
| Water Capacity lt | 170 |
| Chamber Capacity lt | 280 |
| Max. Operating Pressure bar | 3 |
| Test Pressure bar | 4.3 |
| Temperature Control Range °C | 45-85 |
| Max. Operating Temperature °C | 90 |
| Reducer Power W | 180 |
| Fan Power W | 240 |
| Ash Box Capacity l | 50 |
| Operating Voltage and Frequency V/Hz | 230/50 |
| Operating Current A | 16 |
